Proposed by Ant International: https://www.ant-intl.com/en/
Simple Summary
Extend ERC-20 so that a token transfer is valid only when an external “Transfer Oracle” pre-approves it. Approvals reference an off-chain ISO 20022 payment instruction (pain.001 instruction) that is proven on-chain via a zero-knowledge proof. The scheme is issuer-agnostic, proof-system-agnostic, and network-agnostic (L1/L2).
Abstract
This EIP standardises:
ITransferOracle– a minimal interface that any ERC-20-compatible contract can consult to decide whethertransfer/transferFromshould succeed.approveTransferflow – whereby an issuer (token owner) deposits a one-time approval in the oracle, accompanied by a zk-proof attesting that the approval matches a canonicalised ISO 20022 payment message.canTransferquery – whereby the token contract atomically consumes an approval when the holder initiates the transfer.- Generic data structures, events, and hooks that allow alternative permissioning logics (KYC lists, travel-rule attestations, CBDC quotas) to share the same plumbing.
Reference implementation, SDKs, and Solidity templates are provided using RISC Zero as the proving system, but the standard admits any zk-proof system and any JSON (or future XML) schema.
Motivation
Institutional tokenisation requires both ERC-20 fungibility and legally enforceable control over who may send value to whom and why.
Hard-coding rules in every token contract is brittle and non-standard. Centralising rules in a singleton oracle and proving off-chain documentation on-chain gives:
- Compliance traceability – every transfer links to a signed payment
order recognised by traditional finance systems. - Issuer flexibility – any institution can swap out its oracle logic
without breaking ERC-20 compatibility. - Composability – DeFi protocols can interact with permissioned tokens
using familiar ERC-20 flows, while downstream permission checks are
encapsulated in the oracle.
Specification
The key words “MUST”, “MUST NOT”, “REQUIRED”, “SHALL”, “SHALL NOT”, “SHOULD”, “SHOULD NOT”, “RECOMMENDED”, “MAY”, and “OPTIONAL” in this document are to be interpreted as described in RFC 2119.
Interfaces
/// @notice One-time ZK-backed approval for a single transfer.
struct TransferApproval {
address sender;
address recipient;
uint256 minAmt;
uint256 maxAmt;
uint256 expiry; // UNIX seconds; 0 == never
bytes32 proofId; // keccak256(root‖debtorHash‖creditorHash)
}
/// @title External oracle consulted by permissioned tokens.
interface ITransferOracle {
/// @dev Verifies zk-proof and stores a one-time approval.
/// @return proofId – unique handle for off-chain reconciliation
function approveTransfer(
TransferApproval calldata approval,
bytes calldata proof, // ZK proof bytes (system-specific)
bytes calldata publicInputs // ABI-encoded public outputs
) external returns (bytes32 proofId);
/// @dev Atomically consumes an approval that covers `amount`.
/// MUST revert if no such approval exists.
function canTransfer(
address token,
address issuer,
address sender,
address recipient,
uint256 amount
) external returns (bytes32 proofId);
}
ERC-20 Hook
A Permissioned ERC-20 MUST replace the standard internal
_update(address from, address to, uint256 amount) logic with:
bytes32 proofId = ORACLE.canTransfer(address(this), owner(), from, to, amount);
// MUST revert on failure
_super._update(from, to, amount);
emit TransferValidated(proofId);
ORACLE is an immutable constructor argument. (up to design)
Events
event TransferApproved(
address indexed issuer,
address indexed sender,
address indexed recipient,
uint256 minAmt,
uint256 maxAmt,
uint256 expiry,
bytes32 proofId
);
event ApprovalConsumed(
address indexed issuer,
address indexed sender,
address indexed recipient,
uint256 amount,
bytes32 proofId
);
event TransferValidated(bytes32 indexed proofId);
Canonicalisation of ISO 20022 JSON
- Apply RFC 8785: JSON Canonicalization Scheme (JCS).
- Convert numeric amounts to integers of 10⁻³ (milli-units) to avoid floats.
- This means that all monetary amounts in the ISO 20022 payment instructions must be converted from decimal numbers (e.g., 1.50 USD) into integers representing milli-units (e.g., 1500), where:
1 milli-unit = 0.001 (10⁻³) of the base currency unit.
- This means that all monetary amounts in the ISO 20022 payment instructions must be converted from decimal numbers (e.g., 1.50 USD) into integers representing milli-units (e.g., 1500), where:
- UTF-8 NFC normalisation; strip insignificant whitespace.
Merkle-and-Proof Requirements
The merkle tree root is used to verify that the public inputs actually come from the original off-chain payment instruction. The ZK proof system validates that all fields belong to the same committed pain.001 message through Merkle proof verification.
| Public Inputs | Purpose | Rationale |
|---|---|---|
root |
Merkle root of pain.001 message | Data-integrity and field binding |
debtorHash |
Hash of debtor (sender) data | Privacy-preserving identification |
creditorHash |
Hash of creditor (recipient) data | Privacy-preserving identification |
minAmountMilli/maxAmountMilli |
Value bounds in milli-units | Anti-front-running protection |
currencyHash |
Hash of currency code | Currency validation |
expiry |
Execution date as timestamp | Prevents replay and ensures timeliness |
The ZK proof system MUST verify:
- Hash Integrity: All provided hashes match computed hashes of the actual data
- Amount Bounds: The transfer amount falls within the specified range
- Merkle Proofs: All fields (debtor, creditor, amount, currency, expiry) belong to the same committed message
- Expiry Validation: The execution date is consistent and not expired
The oracle MAY accept additional public inputs, e.g., extended currency validation, jurisdiction codes, sanctions list epochs
Proof System Flexibility
This standard is proof-system-agnostic. The reference implementation uses RISC Zero for:
- Transparent Setup: No trusted ceremony required
- Developer Experience: Write verification logic in Rust
- Performance: Efficient proof generation and verification
- Auditability: Clear, readable verification code
However, implementations MAY use any ZK proof system (Groth16, PLONK, STARKs, etc.) as long as they:
- Validate the required public inputs listed above
- Ensure proper Merkle proof verification for field binding
- Maintain the same security guarantees
Upgradeability
- Token and Oracle MAY be behind EIP-1967 proxies.
- Verifier is stateless; safe to swap when a new proof system is adopted.
- Oracle logic can be upgraded independently of token contracts.
Rationale
Keeping oracle logic out of the token contract preserves fungibility and lets one oracle serve hundreds of issuers. TransferApproval uses amount ranges so issuers can sign a single approval before the final FX quote is known. canTransfer returns the proofId, enabling downstream analytics and regulators to join on-chain transfers with off-chain SWIFT messages.
The Merkle proof requirement ensures that all approval data comes from the same authentic pain.001 message, preventing field substitution attacks where an attacker might try to combine legitimate data from different transactions.
Backwards Compatibility
Existing ERC-20 consumers remain unaffected; a failed transfer simply reverts. Wallets and exchanges should surface the oracle’s revert messages so users know they lack approval.
Security Considerations
- Replay Protection – approvals are one-time and keyed by
proofId. - Field Binding – Merkle proofs ensure all approval data comes from the same committed message.
- Oracle Risk – issuers SHOULD deploy dedicated oracles; a compromised oracle only endangers its own tokens.
- Proof System Security – the chosen ZK proof system must provide computational soundness and zero-knowledge properties.
- Hash Function Security – implementations should use cryptographically secure hash functions (e.g., Keccak256, SHA256).
- Amount Validation – strict bounds checking prevents amount manipulation attacks.
Reference Implementation
- Solidity Contracts: Complete implementation with OpenZeppelin v5 compatibility
- RISC Zero Integration: Rust-based guest program for pain.001 validation
- Testing Framework: Comprehensive test suite including unit, integration, and performance tests
- CLI Tools: Host program for proof generation and verification
- Gas Optimization: Efficient on-chain verification with detailed gas profiling
Repository: chadxeth/eip-permissioned-erc20
The reference implementation demonstrates:
- Full ISO 20022 pain.001 message validation
- Merkle proof verification for field integrity
- RISC Zero proof generation and verification
- Integration with standard ERC-20 workflows
- Comprehensive error handling and edge cases
Implementation Status
Completed Features:
- Core smart contracts (PermissionedERC20, TransferOracle, RiscZeroVerifier)
- RISC Zero guest program with full pain.001 validation
- Merkle proof verification system
- Comprehensive test suite with 100% coverage
- Gas optimization and performance validation
- CLI tools for proof generation
- Integration testing framework
Production Ready:
- All contracts compile and deploy successfully
- End-to-end proof generation and verification working
- Extensive testing including edge cases and error conditions
- Performance benchmarks and gas cost analysis
- Security considerations addressed and documented
Copyright
Copyright and related rights waived via CC0
